MedClock 4G Router Setup Guide

Watch the setup video below, then follow the step-by-step instructions.

1. Power On the 4G Router

Plug the supplied USB-C cable into the 4G router and connect it to power.

The router will begin booting. Once powered on, only the bottom-left LED should be illuminated, as shown below.

2. Connect to the 4G Network

Press and hold the side button for approximately 8 seconds, or until all four LEDs illuminate.

Release the button. The LEDs will return to showing only the bottom-left LED.

Leave the router undisturbed for up to 5 minutes while it connects to the 4G network.

3. Confirm the Connection

After approximately 5 minutes, the router should display three illuminated LEDs, as shown below.

Note: Flashing LEDs are completely normal and simply indicate network activity.

If, after 5 minutes, only the bottom-left LED is illuminated:

1. Press and hold the side button for approximately 8 seconds until all four LEDs briefly illuminate.
2. Release the button.
3. Wait another 5 minutes for the router to reconnect.

4. Keep the Router Powered

The 4G router should remain connected to power 24 hours a day, 7 days a week.

The built-in battery backup will keep the router operating for approximately 8 hours during a power outage.

If a power outage lasts longer than 8 hours, reconnect the router to power, then press and hold the side button for approximately 8 seconds to reconnect it to the 4G network.

5. Set Up Your MedClock

Once the router has connected to the 4G network, set up your MedClock as normal.

The Wi-Fi network name (SSID) and Wi-Fi password are printed on the label on the back of the router.
